I wanted a set of scripts that behaved a little bit like the commands in bruker xwin-nmr/topspin, so that I could do some quick processing for visual inspection without having to do too much coding.

I also wanted some simple modules that I can plug into automated processing routines for large numbers of spectra (e.g. when doing kinetics).

So here are a few simple octave routines which should work in matlab as well. They won't change the world, but should be good enough for some basic 1D processing.

Because of the groupdelay (GRPDLY) used in by Bruker (see e.g.

here (16th of June post) and

here), you need to use the bruk2ana converter. There's little science behind the values which are applied since they are hardware specific.

Example workflow:

./bin2ascii experiment_1/1 fid
getpar experiment_1/1 my.par

octave:1> [fid,pars]=loadfid('fid.ascii','my.par');
octave:2> [zfid,pars]=zf(fid,pars);
octave:3> [test,phc1]=bruk2ana(zfid,pars);
octave:4> test=em(test,0.5);
octave:5> plot(test(:,1),test(:,3));
octave:6> spectrum=ft(test,pars);
octave:7> phased=apk(spectrum,phc1);
octave:8> final=absd(spectrum);
octave:9> pltspec(final)

__Linux shell-scripts__

**bin2ascii
**
#!/bin/bash
#bin2ascii dir fid
cp $1/$2 $1/$2.bak
ls $1/$2.bak | cpio -o | cpio -i --swap -u
od -An -t dI -v -w8 $1/$2.bak| gawk '{print NR,$1,$2}' > $2.ascii

**getpars
**
#!/bin/bash
#getpars $1 $2
# $1 is the location (directory or .) and $2 is the root of the output file name
SW=`cat $1/acqus | grep 'SW_h' | sed 's/\=/\t/g' | gawk '{print $2}'| tr -d '\n'`
TD=`cat $1/acqus | grep 'TD=' | sed 's/\=/\t/g' | gawk '{print $2}'| tr -d '\n'`
O=`cat $1/acqus | grep '$O1=' | sed 's/\=/\t/g' | gawk '{print $2}'`
SFO=`cat $1/acqus | grep 'SFO1=' | sed 's/\=/\t/g' | gawk '{print $2}'`
DECIM=`cat $1/acqus | grep 'DECIM=' | sed 's/\=/\t/g' | gawk '{print $2}'`
DSPFVS=`cat $1/acqus | grep 'DSPFVS=' | sed 's/\=/\t/g' | gawk '{print $2}'`
echo $SW > $2
echo $TD >> $2
echo $O >> $2
echo $SFO >> $2
echo $DECIM >> $2
echo $DSPFVS >> $2

__Octave scripts__

**loadfid.m
**
function [fid,pars]=loadfid(infile,parfile)
%%Usage: [fid,pars]=loadfile(infile,parfile)
%%reads a pts, re, im ascii array
%%generated by bin2ascii
%%and a parfile generated with genpar
fid=load(infile);
pars=load(parfile);
t=linspace(0,(1/(pars(1)/(pars(2)/2))),pars(2)/2);
fid=[t' fid(:,2) fid(:,3)];
end

**zf.m**
function [newfid,pars]=zf(fid,pars)
%% Usage:[newfid,updatedpars]=zf(fid,pars)
%% Doubles the number of points by zerofilling
dims=size(fid);
newfid=[fid' zeros(3,dims(1))]';
pars(2)=pars(2)*2;
end

**bruk2ana**
function [fid,phc1]=bruk2ana(fid,pars)
%% Usage: [fid,phc1]=bruk2ana(fid,pars)
%% where phc1 is the first-order phase correction
%% Using https,//nmrglue.googlecode.com/svn-history/r44/trunk/nmrglue/fileio/bruker.py
%% and https,//ucdb.googlecode.com/hg/application/ProSpectND/html/dmx_digital_filters.html
%% The short version is: bruker fid data needs pre-processing and it's hardware dependent
%%D contains the digital filter parameters
D=[[10,2, 44.75];
[10,3, 33.5];
[10,4, 66.625];
[10,6, 59.083333333333333];
[10,8, 68.5625];
[10,12, 60.375];
[10,16, 69.53125];
[10,24, 61.020833333333333];
[10,32, 70.015625];
[10,48, 61.34375];
[10,64, 70.2578125];
[10,96, 61.505208333333333];
[10,128, 70.37890625];
[10,192, 61.5859375];
[10,256, 70.439453125];
[10,384, 61.626302083333333];
[10,512, 70.4697265625];
[10,768, 61.646484375];
[10,1024, 70.48486328125];
[10,1536, 61.656575520833333];
[10,2048,70.492431640625];
[11,2, 46.];
[11,3, 36.5];
[11,4, 48.];
[11,6, 50.166666666666667];
[11,8, 53.25];
[11,12, 69.5];
[11,16, 72.25];
[11,24, 70.166666666666667];
[11,32, 72.75];
[11,48, 70.5];
[11,64, 73.];
[11,96, 70.666666666666667];
[11,128, 72.5];
[11,192, 71.333333333333333];
[11,256, 72.25];
[11,384, 71.666666666666667];
[11,512, 72.125];
[11,768, 71.833333333333333];
[11,1024, 72.0625];
[11,1536, 71.916666666666667];
[11,2048, 72.03125];
[12,2, 46. ];
[12,3, 36.5];
[12,4, 48.];
[12,6, 50.166666666666667];
[12,8, 53.25];
[12,12, 69.5];
[12,16, 71.625];
[12,24, 70.166666666666667];
[12,32, 72.125];
[12,48, 70.5];
[12,64, 72.375];
[12,96, 70.666666666666667];
[12,128, 72.5];
[12,192, 71.333333333333333];
[12,256, 72.25];
[12,384, 71.666666666666667];
[12,512, 72.125];
[12,768, 71.833333333333333];
[12,1024, 72.0625];
[12,1536, 71.916666666666667];
[12,2048, 72.03125];
[13,2, 2.75];
[13,3, 2.8333333333333333];
[13,4, 2.875];
[13,6, 2.9166666666666667];
[13,8, 2.9375];
[13,12, 2.9583333333333333];
[13,16, 2.96875];
[13,24, 2.9791666666666667];
[13,32, 2.984375];
[13,48, 2.9895833333333333];
[13,64, 2.9921875];
[13,96, 2.9947916666666667];];
h=find(D(:,2)==pars(5));
j=find(D(h,1)==pars(6));
magickey=D(h(j),3);
chop=floor(magickey);
phc1=(magickey-chop)*2*pi; %the first-order phase correction gets mangled by bruker
tmp=size(fid); %matlab workaround. rows/columns would be more elegant
newfid=[fid(chop:tmp(1),2:3)' fid(1:chop-1,2:3)']';
fid=[fid(:,1) newfid(:,1) newfid(:,2)];
end

**em.m**
function fid=em(fid,lb)
%%Usage: fid=em(fid,lb)
%%Exponential multiplication window function
%%Increases Signal-to-noise at the expense
%%of resolution
fid(:,2)=fid(:,2).*exp(-lb.*fid(:,1));
fid(:,3)=fid(:,3).*exp(-lb.*fid(:,1));
end

**gm.m**
function fid=gm(fid,lb)
%%Usage: fid=gm(fid,lb)
%%Gaussian multiplication window function
%%Increases Signal-to-noise at the expense
%%of resolution
fid(:,2)=fid(:,2).*exp(-(lb.*fid(:,1)).^2);
fid(:,3)=fid(:,3).*exp(-(lb.*fid(:,1)).^2);
end

**de.m**
function fid=de(fid,lb,gm)
%%Usage fid=de(fid,lb,gm)
%%Double-exponential window function
%%Increases resolution at the expense of
%%signal-to-noise
at=max(fid(:,1));
defun= @(lb,gm,t) (exp(-(t.*lb-gm*at))).^2;
fid(:,2)=fid(:,2).*defun(lb,gm,fid(:,1));
fid(:,3)=fid(:,3).*defun(lb,gm,fid(:,1));
end

**traf.m**
function fid=traf(fid,lb)
%%Usage: fid=traf(fid,lb)
%%TRAF window function
%%Increases resolution at the expense of
%%the signal-to-noise
at=max(fid(:,1));
traffun= @(lb,t) (exp(-t.*lb)).^2./((exp(-t.*lb)).^3+(exp(-at*lb)).^3);
fid(:,2)=fid(:,2).*traffun(lb,fid(:,1));
fid(:,3)=fid(:,3).*traffun(lb,fid(:,1));
end

**ft.m**
function spectrum=ft(fid,pars)
%%Usage: spectrum=ft(fid,pars)
%% Spectrum is a complex array with the frequency in
%%the first column and the real and imaginary parts
%%in the second column
%%pars(3)=centrefreq, pars(1)=SW
spectrum=fftshift(fft(fid(:,3)+i*fid(:,2)));
tmp=size(spectrum);%matlab workaround
freq=linspace(pars(3)+pars(1)/2,pars(3)-pars(1)/2,tmp(1));
spectrum=[freq' spectrum];
endfunction

**apk.m**
function spectrum=apk(spectrum,phc1)
%%Usage spectrum=apk(spectrum,phc1)
%%Spectrum is a complex matrix with
%%the frequency in the first column
%%and the complex spectrum in the
%%second column. phc1 is the first order
%%phase correection
tmp=size(spectrum);
m=720;
ph=linspace(-2*pi,2*pi,m);
maxsig=0;k=1;
minsig=-inf;
for n=1:m;
spex=real( (spectrum(:,2)).*exp(i*(ph(n)+phc1*i/tmp(1))) );
localmin=min(spex);
localmax=max(spex);
if (localmin>minsig)
minsig=localmin;
k=n;
end
end
ph0=ph(k);
spectrum(:,2)=spectrum(:,2).*exp(i*(ph0+phc1*i/tmp(1)));
end

**altapk.m**
function [spectrum,ph]=altapk(spectrum,phc0,phc1)
%%Usage -spectrum,ph]=altapk(spectrum,phc0,phc1)
%%Spectrum is a complex matrix with the frequency in the first column
%%and the complex spectrum in the second column. phc0 and phc1 are the first order
%%phase correction parameters, respectively, and are used as initial guesses.
%%This is an implementation of Chen, Weng, Goh and Garland, J. Mag. Res., 2002, 158, 164-168 and depends on entropy.m.
ph=[phc0;phc1];
ph=minimize("entropy",{ph,spectrum});
%compute spectrum with optimal phase params
pts=linspace(1,size(spectrum(:,2),1),size(spectrum(:,2),1));
phi=(ph(1)+ph(2).*pts./max(pts))';
spectrum(:,2)=spectrum(:,2).*exp(i*phi);
end

**entropy.m**
function E=entropy(ph,spectrum)
%%Used by altapk.m
pts=linspace(1,size(spectrum(:,2),1),size(spectrum(:,2),1));
penalty=5.53;
phi=(ph(1)+ph(2).*pts./max(pts))';
size(phi);
spectrum(:,2)=spectrum(:,2).*exp(i*phi);
R=real(spectrum(:,2));
size(R);
Rm=firstderiv(R);
size(Rm);
h=abs(Rm)/sum(abs(Rm));
size(h);
negs= imag((R).^(1/2));
negs(find(negs>1))=1;
P= @(R) penalty.*sum((negs).*R.^2);
E=-sum(h.*log(h))+P(R);
end

**absd.m**
function spectrum=absd(spectrum)
%%Usage spectrum=absd(spectrum)
%%Simple (linear) baseline correction
bsline=@(m) sum(abs(real(spectrum(:,2))-m));
guess=0;
p=0;
newm=minimize(bsline,p);
spectrum(:,2)=spectrum(:,2)-newm;
end

**pltspec.m**
function pltspec(spectrum)
%%Usage: pltspec(spectrum)
%%Where spectrum is a complex matrix
%%with the frequency in the first column
%%and the complex spectrum (a+i*b) in the
%%second column
plot(spectrum(:,1),real(spectrum(:,2)))
end
